INTERFINE CHEMICALS > Flash Purification - UPFP > puriFlash 5.007

puriFlash® 5.007

P/N: PFG5L0
Specification_5007_Interchim_0418

Process  - Kilo-Lab


  Reliability & robustness with significant loading capacity.
Its reliability, its robustness over the time as well as its security features are the essential assets to make semi-continuous productions effective up to hundreds of grams of compound of interest.
Continuity of production on the same device independently of the scale-up factor.

    Small Organic molecules 5_Stars_Interchim_0418
Impurities Identification 0_Stars_Interchim_0418
Natural Products 3_Stars_Interchim_0418
Peptides, Oligonucleotides 3_Stars_Interchim_0418
Proteins, Bio-drugs 2_Stars_Interchim_0418
Metabolites Isolation 2_Stars_Interchim_0418
Traces Enrichment 5_Stars_Interchim_0418

PF_5007_Interchim_0418

Flash_Go_Interchim_0418 Flash&Go Load_Go_Interchim_0418 Load& Go  Boost_Go_Interchim_0418  Boost&Go  RFID_Interchim_0418


Pump   Injection   Columns Holder
Flow rate: 750mL/min
Pressure max.: 7bar
Quaternary Gradient
Washing discs
Solvent tray with drainage system
  Injection mode: liquid - Dry-load   Integrated
Pre-column holder


Detector   Fraction Collector   System Optimization
UV: 200 - 400nm
multi wavelength & scan collection
Spectral view & purity confirmation
  3 racks Gen5
132 tubes 18x150mm
  Tubings: 2.4mm id
Flow cell-optical length: 0.3mm / 80µL

Unit control   Software   Safety
Touch screen 15"
USB x 8
RJ45
  InterSoft® X "Genius"   Leak detection (pump, FC, …)
Solvent tray w/drainage system
Collector w/drainage system
Solvent level monitoring
RFID
Fume Encloser

Option pack have to be ordered with the purchase of the instrument.


available Peripheral
  pack-UVextended    Machine_Size_Interchim_0418
puriVapTM-6 Check_Interchim_0418   UV: 200 - 800 nm
MS simple Quad APCI- 1200m/z
or 2000m/z
No_Check_Interchim_0418   multi wavelength & scan collection
Refractive Index No_Check_Interchim_0418   P/N: UVEX00
Super loop via external pump Check_Interchim_0418
Auto-Sampler No_Check_Interchim_0418
2nd Collector Check_Interchim_0418
CarouXel No_Check_Interchim_0418       W: 15.75´´ - 40.0cm
D: 20.0" - 51.0cm
H: 29.5" 75.0cm
Multi-waste 1 inlet / 6 outlet electrical valve Check_Interchim_0418
