REGLO Digital
Characteristics
- compact multi-channel tubing pump
- for low-flow, multi-channel fluid transfer and dosing or filling applications
- 6, 8 and 12 roller rotors for extremely low pulsation
- 6 operating modes and calibration functions
- MS/CA Click´n´go cassettes providing defined
and reproducible occlusion conditions
- remote controllable via PC (RS232)
Flow rates: 0.001 – 68ml/min (per channel)
Channels: 2 or 4
| Model |
Order No. |
Channels |
Flow rates
ml/ min per channel |
Pump
rollers |
| REGLO Digital MS-2/6 |
ISM 831 |
2 |
0.003 – 68 |
6 |
| REGLO Digital MS-2/8 |
ISM 832 |
2 |
0.002 – 57 |
8 |
| REGLO Digital MS-2/12 |
ISM 596 |
2 |
0.002 – 38 |
12 |
| REGLO Digital MS-4/6 |
ISM 833 |
4 |
0.002 – 43 |
6 |
| REGLO Digital MS-4/8 |
ISM 834 |
4 |
0.002 – 35 |
8 |
| REGLO Digital MS-4/12 |
ISM 597 |
4 |
0.001 – 24 |
12 |
| 6 rollers = higher flow rate - 12 rollers = less pulsation |
 REGLO Analog
Characteristics
- no LED display
- no calibration functions
- only "Start/Stop", "Speed" and "Direction"
Flow rates: 0.002 – 68 ml/min (per channel)
Speed setting: 2-digit potentiometer, 1% steps
Remote control: analog interface (no RS232)
| Model |
Order No. |
Channels |
Flow rates
ml/ min per channel |
Pump
rollers |
| REGLO Analog MS-2/6 |
ISM 830 |
2 |
0.005 – 68 |
6 |
| REGLO Analog MS-2/8 |
ISM 829 |
2 |
0.004 – 57 |
8 |
| REGLO Analog MS-2/12 |
ISM 795 |
2 |
0.003 – 38 |
12 |
| REGLO Analog MS-4/6 |
ISM 828 |
4 |
0.003 – 43 |
6 |
| REGLO Analog MS-4/8 |
ISM 827 |
4 |
0.003 – 35 |
8 |
| REGLO Analog MS-4/12 |
ISM 796 |
4 |
0.002 – 24 |
12 |
| 6 rollers = higher flow rate - 12 rollers = less pulsation |
IPC and IPC-N
Microprocessor controlled dispensing pump
Characteristics
- microprocessor controlled drive
- 11 operating modes and calibrating functions
- extremely low pulsation
- for low-flow, multi-channel fluid transfer and dosing or filling applications
- flow rate and dispensing volume can be calibrated
- planetary drive for very accurate pumping
- high repeatability on all channels
- 8 actively driven stainless steel rollers
- CA Click´n´go cassettes providing defined and repeatable occlusion conditions
- remote controllable via PC (RS232)
- paint finished stainless steel housing
Flow rates
- 0.0004 – 11 ml/min (per channel) (IPC-N Series)
- 0.002 – 44 ml/min (per channel) (IPC Series)
Channels: 4, 8, 12, 16 or 24
Operating panel
- 6-button membrane key-pad with LED display
- various operating modes for dosing applications
Speed setting
- in %, resolution 0.1% (rpm)
- in µl/min or ml/min (flow rate)
Speed control: closed loop control for load independent speed
Remote control
- RS232 "in" and "out"
- digital inputs (TTL level)
- analog input for speed control
- analog output for speed monitoring
| Model |
Order No. |
Channels |
Flow rates
ml/ min per channel |
Dimensions |
Weight |
| D x W x H (mm) |
D x W x H (inches) |
kg |
Id |
| IPC 4 |
ISM 930 |
4 |
0.002 – 44 |
180 x 175 x 130 |
7 1/16 x 6 7/8 x 5 1/8 |
4.6 |
10 |
| IPC 8 |
ISM 931 |
8 |
|
220 x 175 x 130 |
8 2/3 x 6 7/8 x 5 1/8 |
5.1 |
12 |
| IPC 12 |
ISM 932 |
12 |
|
260 x 175 x 130 |
10¼ x 6 7/8 x 5 1/8 |
5.8 |
13 |
| IPC 16 |
ISM 933 |
16 |
|
300 x 175 x 130 |
11 7/8 x 6 7/8 x 5 1/8 |
6.5 |
15 |
| |
|
|
|
|
|
|
|
| IPC-N 4 |
ISM 935 |
4 |
0.0004 – 11 |
180 x 175 x 130 |
7 1/16 x 6 7/8 x 5 1/8 |
4.6 |
10 |
| IPC-N 8 |
ISM 936 |
8 |
|
220 x 175 x 130 |
8 2/3 x 6 7/8 x 5 1/8 |
5.1 |
12 |
| IPC-N 12 |
ISM 937 |
12 |
|
260 x 175 x 130 |
10¼ x 6 7/8 x 5 1/8 |
5.8 |
13 |
| IPC-N 16 |
ISM 938 |
16 |
|
300 x 175 x 130 |
11 7/8 x 6 7/8 x 5 1/8 |
6.5 |
15 |
| IPC-N 24 |
ISM 939 |
24 |
|
380 x 175 x 130 |
15 x 6 7/8 x 5 1/8 |
7.9 |
18 |
IP and IP-N
Characteristics
- no dispensing features
- no calibrating functions
- only Run/Stop, Speed Control and Direction
Flow rates
- 0.0004 – 11 ml/min (per channel) (IP-N Series)
- 0.002 – 44 ml/min (per channel) (IP Series)
Channels: 4, 8, 12, 16 or 24
Operating panel
- 6-button membrane key-pad with LED display
- 2 LEDs indicating LOCAL and REMOTE operation
Speed setting
- in rpm, resolution 0.1 rpm (IP) or 0.03 rpm (IP-N)
- in %, resolution 0.1% (rpm)
Remote control: analog interface (no RS232)
| Model |
Order No. |
Channels |
Flow rates
ml/ min per channel |
Dimensions |
Weight |
| D x W x H (mm) |
D x W x H (inches) |
kg |
lb |
| IP 4 |
ISM 940 |
4 |
0.002 – 44 |
180 x 175 x 130 |
7 1/16 x 6 7/8 x 5 1/8 |
4.6 |
10 |
| IP 8 |
ISM 941 |
8 |
|
220 x 175 x 130 |
8 2/3 x 6 7/8 x 5 1/8 |
5.1 |
12 |
| IP 12 |
ISM 942 |
12 |
|
260 x 175 x 130 |
10¼ x 6 7/8 x 5 1/8 |
5.8 |
13 |
| IP 16 |
ISM 943 |
16 |
|
300 x 175 x 130 |
11 7/8 x 6 7/8 x 5 1/8 |
6.5 |
15 |
| IP 24 |
ISM 944 |
24 |
|
380 x 175 x 130 |
15 x 6 7/8 x 5 1/8 |
7.9 |
18 |
| |
|
|
|
|
|
|
|
| IP-N 4 |
ISM 945 |
4 |
0.0004 – 11 |
180 x 175 x 130 |
7 1/16 x 6 7/8 x 5 1/8 |
4.6 |
10 |
| IP-N 8 |
ISM 946 |
8 |
|
220 x 175 x 130 |
8 2/3 x 6 7/8 x 5 1/8 |
5.1 |
12 |
| IP-N 12 |
ISM 947 |
12 |
|
260 x 175 x 130 |
10¼ x 6 7/8 x 5 1/8 |
5.8 |
13 |
| IP-N 16 |
ISM 948 |
16 |
|
300 x 175 x 130 |
11 7/8 x 6 7/8 x 5 1/8 |
6.5 |
15 |
| IP-N 24 |
ISM 949 |
24 |
|
380 x 175 x 130 |
15 x 6 7/8 x 5 1/8 |
7.9 |
18 |
Other models available on request.
|
